Handle bracket as standard version for KDAG 41, A/KHA 21/41/42/82.
Hot-dip galvanized, according to BS 729 (DIN EN ISO 1461)
| width | length | PmaxMaximum load | weight | ||
|---|---|---|---|---|---|
| KA 41-010F | 100 mm | 125 mm | 4.3 kN | 1 kg | |
| KA 41-015F | 150 mm | 175 mm | 4.3 kN | 1.1 kg | |
| KA 41-020F | 200 mm | 225 mm | 4.3 kN | 1.2 kg | |
| KA 41-025F | 250 mm | 275 mm | 4.3 kN | 1.4 kg | |
| KA 41-030F | 300 mm | 325 mm | 4.3 kN | 1.5 kg | |
| KA 41-040F | 400 mm | 425 mm | 4.3 kN | 1.6 kg | |
| KA 41-050F | 500 mm | 525 mm | 4.3 kN | 1.8 kg | |
| KA 41-060F | 600 mm | 625 mm | 4.3 kN | 1.9 kg |
