flame-resistant according to specification of UL94 V-0 and fire hazard testing VDE 0471/DIN IEC 695 part 2-1, testing temperature Tmax
The information on the number of cables relating to the use of NYM cable (3 x 1.5 mm²).
Polyamide
| number of cables Maximum number of installable cables | color | weight | PT test temperature | ||
|---|---|---|---|---|---|
| SH 15 ND K | 15 | RAL 7035 | 0.04 kg | 750 °C | |
| SH 30 ND K | 30 | RAL 7035 | 0.06 kg | 750 °C | |
| SH 15 ND FWK | 15 | RAL 7030 | 0.04 kg | 960 °C | |
| SH 30 ND FWK | 30 | RAL 7030 | 0.06 kg | 960 °C |
