The KLTR girder clamp is used to clamp cable trays to horizontally crossing steel girders. Offset placement of the clamp prevents movement in the longitudinal direction. Two notch points on the clamping leg allow the leg to be adapted to shorter girder flanges. For beam flange thickness 5 - 22 mm. Compatible from R(G) 60.
Continously hot galvanized (Sendzimir process) (DIN EN 10346)
| height | width | t material thickness | weight | ||
|---|---|---|---|---|---|
| KLTR S | 75 mm | 150 mm | 2,5 mm | 0,17 kg |
Hot-dip galvanized, according to BS 729 (DIN EN ISO 1461)
| height | width | t material thickness | weight | ||
|---|---|---|---|---|---|
| KLTR F | 75 mm | 150 mm | 2,5 mm | 0,18 kg |
Stainless steel, according to ASTM 304 / BS 304 S 3
| height | width | t material thickness | weight | ||
|---|---|---|---|---|---|
| KLTR E | 75 mm | 150 mm | 2,5 mm | 0,17 kg |
