HK 30-70 cable hook

Cable hook galvanized, for provisional laying of cables with a diameter up to 70 mm.

Hot-dip galvanized, according to BS 729 (DIN EN ISO 1461)

	H_maxMaximum height	height	width	diameter	weight
HK 30	105 mm	105 mm	30 mm	≤ 30 mm	9.8 kg/100
HK 40	110 mm	110 mm	30 mm	≤ 40 mm	11 kg/100
HK 50	130 mm	130 mm	30 mm	≤ 50 mm	13.1 kg/100
HK 60	150 mm	150 mm	30 mm	≤ 60 mm	15.1 kg/100
HK 70	170 mm	170 mm	30 mm	≤ 70 mm	16.2 kg/100
