WLD-SW storm protection angle - wide-span cable tray

The storm protection bracket WLD-SW is used to additionally secure wide-span cover when used outdoors. At least 6 safety elements must be used per 3 metres of cable tray cover according to the installation instructions. In wind-exposed areas, the number of cover clips must be increased to at least 10. The storm protection bracket is placed on top of the wide-span cover from the outside and bolted in place. It is made of hot-dip galvanised steel.
