The floor channel lid hinge BKD-S connects the lid BKD-RHP with the floor channel BK. In this way, the lid can be opened. The hinge fits the pre-stamped knock-out slugs in the BK and BKD-RHP. The slugs must be knocked out and the hinge screwed in place using the KLR clamp fastening set. Three hinges are recommended for the BKD-RHP cover, two hinges for the BKD-RHP short pieces (1.5m and 1m).
Continously hot galvanized (Sendzimir process) (DIN EN 10346)
| length | width | height | t material thickness | weight | ||
|---|---|---|---|---|---|---|
| BKD-S S | 50 mm | 30 mm | 50 mm | 2 mm | 0,082 kg |
