RS 60 cable tray, unperforated, heavy, height = 60 mm

Downloads

heavy cable tray, not perforated, head shape suitable for positive locking covers, certified including electrical conductivity according to DIN EN 61537/VDE 0639

Do not walk upon!

Continously hot galvanized (Sendzimir process) (DIN EN 10346)

	height	width	length	t material thickness	A cross section area	Q_SKdistributed load control cable	weight
RS 60-10S	60 mm	100 mm	3000 mm	1.50 mm	57 cm²	0.09 kN/m	9.00 kg
RS 60-20S	60 mm	200 mm	3000 mm	1.50 mm	117 cm²	0.18 kN/m	12.60 kg
RS 60-30S	60 mm	300 mm	3000 mm	1.50 mm	177 cm²	0.27 kN/m	16.10 kg
RS 60-40S	60 mm	400 mm	3000 mm	1.50 mm	237 cm²	0.36 kN/m	19.60 kg
RS 60-50S	60 mm	500 mm	3000 mm	1.50 mm	297 cm²	0.45 kN/m	23.20 kg
RS 60-60S	60 mm	600 mm	3000 mm	1.50 mm	357 cm²	0.54 kN/m	26.70 kg

Hot-dip galvanized, according to BS 729 (DIN EN ISO 1461)

	height	width	length	t material thickness	A cross section area	Q_SKdistributed load control cable	weight
RS 60-10F	60 mm	100 mm	3000 mm	1.50 mm	57 cm²	0.09 kN/m	9.60 kg
RS 60-20F	60 mm	200 mm	3000 mm	1.50 mm	117 cm²	0.18 kN/m	13.30 kg
RS 60-30F	60 mm	300 mm	3000 mm	1.50 mm	177 cm²	0.27 kN/m	17.10 kg
RS 60-40F	60 mm	400 mm	3000 mm	1.50 mm	237 cm²	0.36 kN/m	20.80 kg
RS 60-50F	60 mm	500 mm	3000 mm	1.50 mm	297 cm²	0.45 kN/m	24.60 kg
RS 60-60F	60 mm	600 mm	3000 mm	1.50 mm	357 cm²	0.54 kN/m	28.30 kg
