RB 85 cable tray bend, height = 85 mm

Downloads

cable tray bend 90º for horizontal change of direction with integrated connectors

UL classified

Continously hot galvanized (Sendzimir process) (DIN EN 10346)

	height	width	weight
RB 85-10S	85 mm	100 mm	1.2 kg
RB 85-20S	85 mm	200 mm	1.5 kg
RB 85-30S	85 mm	300 mm	2 kg
RB 85-40S	85 mm	400 mm	2.6 kg
RB 85-50S	85 mm	500 mm	3.4 kg
RB 85-60S	85 mm	600 mm	4.4 kg

Hot-dip galvanized, according to BS 729 (DIN EN ISO 1461)

	height	width	weight
RB 85-10F	85 mm	100 mm	1.2 kg
RB 85-20F	85 mm	200 mm	1.6 kg
RB 85-30F	85 mm	300 mm	2.1 kg
RB 85-40F	85 mm	400 mm	2.8 kg
RB 85-50F	85 mm	500 mm	3.6 kg
RB 85-60F	85 mm	600 mm	4.7 kg
